10' Inch Heavy-Duty In-Vehicle Tablet
10.1" Android 9.0 in-vehicle rugged tablet with 1000-nit sunlight display, Qualcomm A53 octa-core 1.8GHz, LTE/Wi-Fi ac/BT 4.2, multi-GNSS with optional RTK (±2.5cm), rich I/O (RS232/RS485/CAN/RJ45/GPIO/AHD In), and ISO 7637-II 8–36V.
Key Features & Benefits
TRIDEN AT-10A is a 10-inch in-vehicle rugged Android tablet built for outdoor and industrial applications. Running Android 9.0 on a Qualcomm Cortex-A53 octa-core 1.8 GHz with Adreno 506, it combines a 1000-nit sunlight-readable display, LTE/HSPA+, dual-band Wi-Fi, Bluetooth 4.2, and multi-GNSS. Optional professional RTK enables ±2.5 cm positioning for precision agriculture and similar use cases. With IP67/MIL-STD-810G durability, ISO 7637-II surge protection (8–36 V), MDM support, and a full suite of vehicle interfaces, AT-10A integrates seamlessly with fleets and field systems.
1000-nit Sunlight Screen
10.1" 1280×800 IPS panel remains readable in bright outdoor environments; glove/wet touch customizable.
Octa-core Performance
Qualcomm Cortex-A53 64-bit octa-core @ 1.8GHz with Adreno 506 (OpenGL ES 3.1) for smooth multitasking.
Android 9.0 Platform
Stable OS for industrial apps; integrated MDM enables real-time device status, remote control and management.
Always Connected
LTE/HSPA+/UMTS/EDGE/GPRS/GSM (data & voice), dual-band 802.11 a/b/g/n/ac Wi-Fi, and Bluetooth 4.2 BLE.
High-Precision GNSS
Standalone ≈2.5 m CEP; optional RTK module achieves ±2.5 cm + 1 ppm horizontal/vertical for precision agriculture.
Rich Vehicle I/O
RS232×2, RS485×1, CAN 2.0b×2, RJ45 10/100, GPIO In×4/Out×4, Analog In (0–30V), ACC, DC, plus optional 2× AHD 1080P video inputs.
Rugged & Automotive-Grade
IP6x/IPx7 ingress protection, MIL-STD-810G vibration; ISO 7637-II transient protection (up to ~174V/300ms), 8–36V input.
Peripheral-Ready
USB-C 3.0 OTG (data), USB-A, 3.5mm headset, internal mics, 2W/8Ω 90dB speaker; optional UHF radio.
Applications
TRIDEN AT-10A various applications
Precision Agriculture
±2.5 cm RTK (optional), CAN/GPIO integration, bright HMI for tractors.
Logistics & Fleet
Dispatch, navigation, ePOD, telemetry over RS/CAN/LAN.
Public Transport
AHD camera preview, fare/peripheral connectivity, robust power.
Industrial Fieldwork
Rugged tablet for inspection, control, and data collection.
Technical Specifications
Complete technical specifications for the 10' Inch Heavy-Duty In-Vehicle Tablet
| Specification | Details |
|---|---|
| System | CPU: Qualcomm Cortex-A53 64-bit Octa-core @ 1.8 GHz GPU: Adreno 506 (OpenGL ES 3.1) Operating System: Android 9.0 RAM: 2 GB LPDDR3 (default) / 4 GB (optional) Storage: 16 GB eMMC (default) / 64 GB (optional) Storage Expansion: MicroSD up to 512 GB |
| Display & Touch | LCD: 10.1" HD (1280×800), 1000 nits, sunlight readable Touch: Multi-touch capacitive; glove & wet modes customizable |
| Audio | Speaker: Built-in 2 W, 8Ω, 90 dB Microphones: Internal microphones Headset: 3.5 mm jack ×1 |
| Sensors | Integrated: Gyroscope, Accelerometer (G-sensor), Ambient light sensor, Compass |
| On-Device Interfaces | USB-C: Type-C (USB 3.0), data transfer; OTG supported USB-A: USB (Type-A) |
| Vehicle / External Interfaces | RS232: ×2 RS485: ×1 CANBUS: CAN 2.0b ×2 RJ45: 10/100 Mbps ×1 GPIO: Input ×4, Output ×4 Analog In: ×1 (0–30 V) ACC: ×1 (ignition) DC: ×1 (power input) AHD Video: Optional ×2 (1080P) |
| Communications | Bluetooth: 4.2 BLE WLAN: IEEE 802.11 a/b/g/n/ac (2.4/5 GHz) Mobile: LTE / HSPA+ / UMTS / EDGE / GPRS / GSM (data & voice) GNSS: Standalone ≈ 2.5 m CEP; RTK (opt): ±2.5 cm + 1 ppm (H/V) Radio: UHF (optional) |
| Ruggedness & Environment | Vibration: MIL-STD-810G Dust: IP6x (IEC 60529) Water: IPx7 (IEC 60529) Operating Temp: −20 °C ~ +65 °C (−4 °F ~ +149 °F) Storage Temp: −20 °C ~ +70 °C (−22 °F ~ +158 °F) |
| Power | Vehicle Power: DC 8–36 V (ISO 7637-II compliant) Transient Immunity: Withstands up to ~174 V / 300 ms surge |
| Physical | Dimensions: 273 × 183 × 49 mm (W×H×D) Weight: ≈ 1.6 kg |
Accessories & Integration
Complete your AT-10A setup with professional accessories and integration options
Torx Screwdriver & Screws
Mounting and service fasteners (set).
Power Cable
Vehicle power harness for DC/ACC connection.
LTE Antenna
External LTE antenna for enhanced signal (optional).
Deploy AT-10A Across Your Operations
Sunlight-readable 10" rugged Android tablet with optional RTK, rich vehicle I/O, and ISO 7637-II protection.
