AI MDVR 8 Channel
8-channel 1080P AHD AI Mobile DVR with H.265, 4G/GPS/Wi-Fi, HDD+SD mirror storage, UPS (8–10s), OTA updates, and ADAS/DMS support.
Key Features & Benefits
TRIDEN FS814 AI MDVR is a 1080P AHD hard-disk Mobile Vehicle DVR supporting up to 8 cameras at full HD with embedded 4G, GPS, and Wi-Fi. It enables real-time monitoring, video transmission, intercom, driver ID, route monitoring, segmented speed limits, overspeed reminders, fatigue/distraction alerts, vehicle condition analysis, and ADAS/DMS features. With H.265 compression, UPS power-loss protection (8–10s), HDD heating, wide 10–36V input, and mirror recording to SD, FS814 is engineered for demanding fleet deployments.
8×1080P AHD Recording
Hybrid DVR supports AHD/CVI/TVI/CVBS inputs with H.265 compression and multi-level image quality.
4G • GPS • Wi-Fi
Real-time preview, transmission, tracking, and remote monitoring via built-in cellular, GNSS, and Wi-Fi modules.
AI Driver Safety
ADAS & DMS for lane/forward warnings, fatigue, distraction, and behavior analytics.
HDD + SD Mirror
2.5″ HDD up to 2TB with SD mirror (up to 128GB) for data integrity; USB backup supported.
UPS & Wide Voltage
10–36V input, low power; UPS ensures 8–10s recording on power loss; HDD heating for harsh environments.
Rich I/O & Sensors
RS232/RS485, G-sensor, alarm I/O, OBD, oil/temperature sensors, POS, LED panels, intercom & TTS.
Applications
TRIDEN FS814 various applications
Logistics Fleets
End-to-end visibility with live tracking, AI safety, and reliable storage.
Public Transport
Multi-cam passenger safety, route monitoring, and remote oversight.
Taxi & Ride-hail
Incident evidence, driver behavior, and real-time dispatch integration.
Emergency & Patrol
Rugged video capture with intercom and broadcast functions.
Technical Specifications
Complete technical specifications for the AI MDVR 8 Channel
| Specification | Details |
|---|---|
| System | OS: Linux Language: English / Chinese / Customized GUI: Graphical UI; remote control setup OSD: Date/time, vehicle ID overlay Security: User/Admin 2-level password |
| Video | Compression: H.265 Inputs: 8× AHD (aviation, 1.0Vp-p, 75Ω); CVI/TVI/CVBS optional Output: 1× CVBS (aviation), 1CH full screen / 4CH view Preview: 1/4CH preview; manual/alarm full-screen Resolutions: 1080P/720P/D1/HD1/CIF (max 8×1080P) Frame Standards: PAL 100f/s; NTSC 120f/s (aggregate) Bitrate Ranges: CIF 256K–1.5Mbps; HD1 600K–2.5Mbps; D1 800K–3Mbps; 720P 4–6Mbps; 1080P 4–8Mbps Record Modes: Auto on power, timer, alarm, manual |
| Audio | Inputs: 8CH aviation plug Outputs: 2CH (front headphone, rear BNC) Compression: G.726 (≈8KB/s) |
| Alarms & Interfaces | Alarm Inputs: 6× DI, 1× AD, impulse speed; linkage supported Alarm Outputs: 2× DO; light/sound; oil/power cut-off Serial Ports: 2× RS232 (OBD, POS, fuel, LED), 1× RS485 (PTZ) Sensors: Built-in GPS/BD; G-sensor; OBD support Comms: 3G (WCDMA/CDMA2000/GPRS/EDGE); 4G (TDD-LTE/FDD-LTE); Wi-Fi Voice/Intercom: VOIP intercom; TTS broadcast; text/broadcast |
| Storage & Updates | HDD: 2.5″ up to 2TB (with heating) SD Card: Up to 128GB (mirror recording) File System: Exclusive pre-allocate FS on FAT32 (anti-fragment) Formats: H.265 Updates: USB / SD / OTA remote Backup: Front USB for U-disk/HDD backup |
| AI & Optional | AI Functions: ADAS (LDW/FCW), DMS (fatigue/distraction), behavior analysis Expand: LED ad panel, oil sensor, POS, station broadcaster, OBD, temp sensor Mobile Apps: iOS/Android remote monitor |
| Power & Environment | Power Mgmt: Timed/delay off; UPS 8–10s after power failure Input Voltage: DC +10V ~ +36V Outputs: +12V~1.5A, +5V~1.5A Power: < 5W (working) Operating Temp: -20°C ~ +70°C Humidity: 20% ~ 80% |
| Physical | Dimensions: 218(D) × 161(W) × 65(H) mm Net Weight: 2.2 kg Connectors: Aviation-grade for video/audio/power |
Accessories & Integration
Complete your FS814 setup with professional accessories and integration options
FS814 DVR Unit
8-channel AI MDVR with aviation connectors and HDD bay.
Power & I/O Harness
Vehicle-grade wiring for power, alarms, serial, and comms.
User Manual
Installation, configuration, and operating guide.
Deploy FS814 Across Your Fleet
Combine 8×1080P recording, AI safety, resilient storage, and remote monitoring in one rugged platform.
